Eminence LIL" BUDDY 10" Guitar Speaker 50 Watts
Eminence LIL" BUDDY 10" Guitar Speaker 50 Watts
The Eminence Lil' Buddy guitar speaker lets you push the limits. Clean and full, and slow to break-up. Crunchy when driven. A much smoother and less brittle tone than many 10 inch guitar speakers.
SPECIFICATION | |
Nominal Basket Diameter | 10", 254 mm |
Nominal Impedance* | 8 Ω |
Power Rating* | |
Program Power | N/A |
Watts | 50 W |
Resonance | 149 Hz |
Usable Frequency Range | 80 Hz - 5 kHz |
Sensitivity* | 98.8 dB |
Magnet Weight | 30 oz. |
Gap Height | 0.312", 7.9 mm |
Voice Coil Diameter | 1.75", 44 mm |
THIELE & SMALL PARAMETERS | |
Resonant Frequency (fs) | 149 Hz |
DC Resistance (Re) | 6.31 Ω |
Coil Inductance (Le) | 0.46m H |
Mechanical Q (Qms) | 9.06 |
Electromagnetic Q (Qes) | 0.93 |
Total Q (Qts) | 0.84 |
Compliance Equivalent Volume (Vas) | 10 liters / 0.35 cu.ft. |
Peak Diaphragm Displacement Volume (Vd) | 29.3 cc |
Mechanical Compliance of Suspension (Cms) | 0.05 mm/N |
BL Product (BL) | 11.7 T-M |
Diaphragm Mass Inc. Airload (MMs) | 22 grams |
Efficiency Bandwidth Product (EBP) | 160 |
Maximum Linear Excursion (Xmax) | 0.8 mm |
Surface Area of Cone (Sd) | 366.1 cm2 |
Maximum Mechanical Limit (Xlim) | N/A |
MOUNTING INFORMATION | |
Recommended Enclosure Volume | |
Sealed | Acceptable |
Vented | Acceptable |
Driver Volume Displaced | 0.039 cu.ft. / 1.1 liters |
Overall Diameter | 10.11", 256.8 mm |
Baffle Hole Diameter | 9.13", 231.9 mm |
Front Sealing Gasket | Yes |
Rear Sealing Gasket | Yes |
Mounting Holes Diameter | 0.23", 5.8mm |
Mounting Holes B.C.D. | 9.6", 243.8mm |
Depth | 4.3", 109.2 mm |
Net Weight | 6.3 lbs, 2.86 kg |
Shipping Weight | 7.4 lbs, 3.36 kgs |
MATERIALS OF CONSTRUCTION | |
Coil Construction | Copper voice coil |
Coil Former | Paper former |
Magnet Composition | Ferrite magnet |
Core Details | Non-vented core |
Basket Materials | Pressed steel basket |
Cone Composition | Hemp cone ? |
Cone Edge Composition | Paper cone edge |
Dust Cap Composition | Zurette dust cap |
