WGS Blackhawk HP ALNICO 12" 100 Watt British Invasion Guitar Speakers
WGS Blackhawk HP ALNICO 12" 100 Watt British Invasion Guitar Speakers
$539.00
539.00
Have a question?
The high-power 12” BlackHawk™ alnico speaker has arrived! Now your 1x12” 100 watt amp can really purr.... This guitar speaker will give your amp pristine top end, tight mids, and all just the right amount of warmth and bottom end. Drop in replacement for EV™ SRO™ speaker.
Unit Weight: 9 pounds
Mounting Information
- Diameter 12.2”
- Overall depth 6.4”
- Cut-out diameter 11.1”
- Mounting slot dimensions 0.31”
- Number of mounting slots: 4
- Mounting slot PCD 11.7”
THIELE-SMALL PARAMETERS
- Resonant Frequency (Fs): 88.14 Hz
- DC Resistance (Re): 7.84 Ohm
- Coil Inductance (Le): 0.35 mH
- Mechanical Q (Qms): 6.32
- Electromagnetic Q (Qes): 1.03
- Total Q (Qts): 0.88
- Compliance Equiv. Vol. (Vas): 21.04 cu ft
- Mech. Compliance of Susp. (Cms): 0.11 mm/N
- BL Product (BL): 11.16 T-M
- Diaphragm Mass Inc. Airload (Mms): 29.46 grams
- Surface Area of Cone (Sd): 366.10 cm squared
- Sound Pressure Level (spl): 99.26 db
