WGS Retro 30 12" 75 Watt British Invasion Guitar Speaker
The 12” Retro 30™ speaker is a brighter and more articulate version of the WGS Veteran 30™ speaker. The Retro 30™ also boasts deeper and tighter bottom end. This speaker is extremely versatile and comes alive on the dirty channel. For those who love to mix speakers, you should pair this with the Reaper™ or the ET65™.
Weight: 4.6kg
Mounting Information
- Diameter 12.2”
- Overall depth 5.3”
- Cut-out diameter 11.1”
- Mounting slot dimensions 0.31”
- Number of mounting slots: 4
- Mounting slot PCD 11.7”
THIELE-SMALL PARAMETERS
- Resonant Frequency (Fs): 103.76 Hz
- DC Resistance (Re): 8.04 Ohm
- Coil Inductance (Le): 0.33 mH
- Mechanical Q (Qms): 9.73
- Electromagnetic Q (Qes): 0.75
- Total Q (Qts): 0.70
- Compliance Equiv. Vol. (Vas): 16.28 cu ft
- Mech. Compliance of Susp. (Cms): 0.09 mm/N
- BL Product (BL): 13.85 T-M
- Diaphragm Mass Inc. Airload (Mms): 27.48 grams
- Surface Area of Cone (Sd): 366.10 cm squared
- Sound Pressure Level (spl): 99.63 db
